Trinocular Stereo Zoom Microscope RSM-9

Name: Trinocular Stereozoom Microscope
Brand: RADICAL SCIENTIFIC EQUIPMENTS PVT. LTD.
Price: 55000.0 INR
Availability: InStock

55000.0 INR/Piece

Get a Price/Quote

Product Details:

Application INDUSTRY, QC, INSTITUTES
Classification MANUAL
Voltage 6 Volt (v)
Usage INSPECTION
Color OFF WHITE
Product Type TABLE TOP
Operate Method MANUAL
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Trinocular Stereo Zoom Microscope RSM-9 Price And Quantity

Price 55000.0 INR/Piece
Minimum Order Quantity 1 Piece
Price Range 59600.00 - 95000.00 INR/Piece

Trinocular Stereo Zoom Microscope RSM-9 Product Specifications

Eyepiece Tube TRINOCULAR
Drawtube Trinocular
Working Stage Large stage with Handrest Square Millimeter (mm2)
Voltage 6 Volt (v)
Usage INSPECTION
Illumination 3W LED (transmitted and reflected), separate intensity controller & on/off switch
Frame Rate NA
Application INDUSTRY, QC, INSTITUTES
Eyepieces Paired, WF 10X, FOV-20mm, high point, multilayered coated, high quality, good contrast, aberration free, aplantic, lockable, eyecups
Interface NA
Classification MANUAL
Still Image Capture Resolution NA
View Head Trinocular
Light Source LED & HALOGEN
Resolution NA
Magnification 3.5x to 160x
Power 20 Watt (w)
Weight 10 Kilograms (kg)
Material DIE CASTING
Focal Distance Plain focusing, working distance 118mm Millimeter (mm)
Video Capture Resolution NA
Image Format NA
Theory Stereo Microscope
Objective Achromatic Long Working Distance
Color OFF WHITE
Product Type TABLE TOP
Operate Method MANUAL

Trinocular Stereo Zoom Microscope RSM-9 Trade Information

Payment Terms Cash Advance (CA), Cash in Advance (CID), Telegraphic Transfer (T/T)
Supply Ability 50 Piece Per Month
Delivery Time 2 Week
Sample Policy Contact us for information regarding our sample policy
Packaging Details Export Worthy Cartons
Main Domestic Market All India
Certifications A GOVT. RECOGNIZED STAR EXPORT HOUSE An ISO 9001:2005, 14001:2015, 13485:2016, FDA, WHO-GMP, CE & BIS Certified Company

Product Description

The special characteristic of Stereo Zoom Microscope is that one can observe the object in three dimensions within the field of view. It is ideally suited for industrial as well as for Biological Research where high precision, maximum working distance and large field coverage is required. The flat field parfocal zoom objectives provide continuously variable magnification from 3.5X to 120X depending upon the eyepieces and auxiliary lenses used.

The Model RSM-9 series offer superior quality optics and reliable mechanical components. This exceptional optical quality allows users to perform tasks efficiently and maintaining high productivity. A wide variety of stands and illuminators are available to suit many different applications. These microscopes feature a zoom magnification from 7x to 60x, zoom ratio 1:8.5, with standard eyepieces WF10x/22mm. The images are sharp, clear flat and having good resolution contrast even at periphery of field. Binocular Body inclined at 45 for fatigue free viewing, can be rotated a full 360 and locked in any position. Ergonomically positioned bilateral ocular tubes are interlocked for improved operatability.
