| Body | RXR4PMB | Rugged, single die cast, ergonomic design, touch point treated, acid resistant texture painted, intensity controller, on/off switch, rubber feet, field diaphragm, Kohler illumination with aperture and field diaphragm, heat protection filter, slot for different compensator, blue filter (45) for white light (4500K), built in handle & cord wrap. |
| Optical system | RXR4PiOS | Strain free, universal infinite optical system, colour/chromatic & spherical abrasion corrected, anti-fungal, anti-bacterial coated (multi-layered hard coated), colour coded objectives, parfocal (45mm) suitable for reflected and transmitted light observation |
| Transmitted Illumination | RXR4PTL20 | Halogen Lamp, 6V/20W, Std. life 2,000 hrs. |
| Viewing Head | RXR4PHB30ST | Binocular with siedentopf head 30, 360 rotating, interpupillary adjustment (48-75mm), FOV 20mm, locking mechanism and orientation key in right eyepiece for the crosshair reticle eyepiece. |
| Nosepiece | RXR4P4N | Objective centrable reverse, precise quadruple nosepiece, revolving on multiple ball bearing, ribbed grip for easy rotation, with slot for Pol & analyzer, compensator, centrable. |
| Eyepiece | RXR4P1020 | Paired, one WF 10X, FOV-20mm, multilayered coated, high quality, antiglare, good contrast, abrasion free, aplanatic, precentered, lockable, with/without eye guard, diopter adjustment and crosshair reticle and pin for orientation in one eyepiece with eye guard. |
| Mechanical Stage | RXR4PMS170 | Large circular rotary stage(lockable), dia. 150mm to 170mm, 360 rotatable, 1 increment, precise vernier scale of 0.1 with click stop at 45 increments. Provision for fixing 2 stage clips; attachable mechanical XY travel 30x40mm, object guide with vernier 0.1mm, centrable, compatible to heating stage, with sample holder, adjustable safety lock. |
| Objectives | RXR4PPF04 | POL PL4X, N.A. 0.10, W.D. 30mm, plan achromatic, suitable for transmitted and reflected illumination |
| | RXR4PPF10 | POL PL10X, N.A. 0.25, W.D. 6.1mm, plan achromatic, suitable for transmitted and reflected illumination |
| | RXR4PPF40 | POL PL40X, N.A. 0.65, W.D. 0.65mm, plan achromatic, spring, suitable for transmitted and reflected illumination |
| Focusing | RXR4PF25 | Coaxial, coarse and fine focus adjustment knobs (low positioned, both side) with rack & pinion arrangement, with tension control, upper limit stopper, full stroke range 30mm, highly sensitive focus drive with 0.25mm per revolution, fine adjustment 2.5m/Div. Upgradable to 35mm stroke range. |
| Retarding Plates | RXR4P-RPLT | Compensator Gypsum 1 plate, (1st order red compensating plate, 560 nanometers) (Mica 1/4 145 nanometers) & quartz wedge in metallic mount of 12mmx4mm, slot for compensator and accessories for above nosepiece at 45. |
| Condenser | RABC | Centerable abbe condenser N.A. 0.9, iris diaphragm, filter slot, separate movement from focusing (rack & pinion) suitable for brightfield and polarizing |
| Analyzer/Polarizer | RXR4PAPOL | 360 rotatable polarizing mount having 0.1 L.C. below the condenser, built in analyzer can be rotate through 45/90/180 with scale removable from optical path with calibrated marking |
| Power supply | RSMPS620 | Integrated SMPS based, wide voltage range, 90V-240V, 50/60Hz |
| Accessories | RCC | Cleaning cloth |
| | RVC | Vinyl cover |
| | RCLP | C-clamp for tension adjustment |
| | RAK | Allen keys & centering tools |
| | RF5A | Fuses - 2 no's |
| | MANUAL | Instruction manual |
| | WARRANTY | Warranty card |
| | RBF | Blue Filter (frosted & Plain) |
| | RPC | Power Cord (country Specific) |
| Holder | | Sample holder, Plan glass reflector Monochromator |
