Product Description
SPECIFICATION: -
PH/Conduclivity/TDS/Salt/Temp Waterproof Tester 7200 is a microprocessor based taster used to determine pH, mV, Temperature, Conductivity, TDS and Salts In a liquid. This tester has wide applications In agriculture, anti-freeze recycling, aquarium, baller, chemical Industry, cooling tower, drinking water, fish farming, food industry, garden husbandry, hydroponics, laboratory usage. plating indus1ry, swimming pool & spa, watertreatment etc.
It has rugged design for field use. It floats on water. It has Automatic Temperature Compensation (ATC) and Is degree C/F switchable. It displays Maximum/Minimum value and data hold on large LCD display. It has low battery and consumption Indicator along with auto shut off after 10 minutes of non use.
FEATURES: -
- Microprocessor Baaed
- IP-57 Water Proofing
- Floats on Water
- Large LCD Display
- Automatic Temperature Compensation (ATC)
- Data Hold, Max/Min and C/F switchable
- Low Battery and Consumption Indicator
- Auto Power-Off after 10 minutes
- Replaceable Sensor
TECHNICAL SPECIFICATION: -
Display Range
Large LCD to display respective parameters, Battery level,ATC & Temp. pH -2 -16.00,
TDS : 0- 1300 ppm
1.30- 13.00 ppt
Cond : 0- 2000 S
2.00 -20.00 ms
mV:-1000 1000 mV
Salt : 0-1000 ppm
1.00 -12.00 ppt
Temp : 0 -90.0 C
32 -194.0 F
Resolution pH : 0.01 pH, mV: 1 mV, TDS: 1 ppm/0.01 ppt,
Conductivity: -1 S/0.01 mS, Temp.: 0.1 C/ F,
Salt :- 1 ppm/0.01 ppt
Accuracy pH : - 0.01 +1 Digit, mV: 2 + 1 Digit,
TDS/Cond/Salt : 2% of F.S., Temp : 0.2 C +1 Digit
Automatic Temp. Automatic Temperature Compensation (ATC) with temperature display.
Temp. Coefficient:-2%per C
Sensor : - User Replaceable
Water Proof : - As per IP 57 water proofing standard
Calibration : - Calibration pH:4.00, 7.00 and 10.01, Cond.: OS, 14135, 12.88 mS
Power : - DCDC 1.5 Vx 4 battery(UM-4/AAA)Auto power off after 10 minutes
Dimensions : - Meter: 195 x 40 x 36 mm (Approx.)
(L x B x H): Kit: 230 x 205 x 50 mm (Approx.) .
Weight Meter : - 135 g with battery, Kit: 780 g
Others Features: - Auto Power-off after 10 minutes, Hold function to freeze reading, Push button calibration, Water-proof IP-57, Temperature coefficient 2% per C, Self-Diagnostics message for low battery
Accessories :- Standard Calibration Solution (50 ml), Battery, Lanyard, Operation Manual and Carrying Case
Superior Measurement VersatilityThe PH/MV/TEMPERATURE-7200 meters simultaneously measure pH, mV, and temperature with high accuracy, catering to laboratory and field settings. Its wide measurement ranges (pH: 0.00-14.00; mV: 1999; Temperature: 0-100C) and switchable temperature compensation enhance versatility and precision across various applications.
User-Friendly Interface and FeaturesThis meter offers a large, clear digital LCD display and straightforward controls, making calibration and operation effortless. With features like auto buffer recognition, last reading recall, and automatic/manual temperature compensation, users experience efficiency and confidence during sample analysis.
Built for Professional DemandsConstructed from durable ABS plastic, the PH/MV/TEMPERATURE-7200 is engineered for portability and resilience. Operating on 230V AC mains or batteries, it is suitable for on-site measurements or continuous use in laboratories, supporting up to 1000 samples per hour without compromising accuracy.
FAQ's of PH/MV/TEMPERATURE- 7200:
Q: How do I calibrate the PH/MV/TEMPERATURE-7200 for pH measurements?
A: You can calibrate the meter using either a 1-point or 2-point pH calibration mode. Simply connect the supplied pH electrode, immerse it in standard buffer solutions, and follow the on-screen instructions for auto buffer recognition and calibration adjustments.
Q: What is the process for switching between automatic and manual temperature compensation?
A: You can select automatic or manual temperature compensation using the device's control settings. For automatic compensation, connect the included temperature probe. For manual mode, input the sample's temperature as directed in the instruction manual.
Q: When should the internal memory's last reading recall feature be used?
A: Use the last reading recall function when you need to verify the most recent sample data without re-measuring, which is particularly useful during busy sample runs or documentation review.
Q: Where can the PH/MV/TEMPERATURE-7200 be effectively utilized?
A: This meter's robust design and portability make it ideal for laboratories, field studies, environmental monitoring, and any other analytical scenario demanding precise pH, mV, and temperature readings.
Q: What accessories are included with the PH/MV/TEMPERATURE-7200?
A: Each unit comes with a pH electrode, temperature probe, instruction manual, and a dust cover, ensuring you have all necessary components for immediate operation and maintenance.
Q: How does the meter benefit laboratory and field analysis work?
A: With its fast sample throughput (up to 1000 samples/hour), accurate measurements (0.01 pH), and lightweight, durable design, the PH/MV/TEMPERATURE-7200 significantly enhances both laboratory productivity and the efficiency of field-based testing.
