Horizontal Profile Projector
Product Code : RPP-50
Brand Name : radical
Product Description
| Screen Diameter | - | 500mm |
| Work Stage | - | 350 x 200mm |
| Stage Travel X-Y axis | - | 150 x 100mm |
| Focusing Range | - | 125mm |
| Magnification Standard | - | 10x |
| Magnification Optional | - | 20x, 25x, 50x, 100x |
| Protector Screen | - | 360° Rotation with 2 minutes vernier resolution |
| Magnification Accuracy | - | ± 0.05% on contour and ± 0.1% on surface |
| Lens Mounting | - | 3 turret type for safety and easy use |
| Resolution | - | 0.01mm |
| Measuring System | - | With Mechanical micrometer 0-25mm / DRO / Data Processor (selectable), (optional PC based software) |
| Illumination | - | 24V, 150W Halogen, Forced Air cooled, Light intensity controller |
| Filter colour | - | Green (Yellow - option) |
| Power Supply | - | AC Single Phase 230V, 50Hz |
| Standard Accessories | - | Supplied complete as above, with standard multilayer coated objective, spare bulb, a vinyl cover and operating instructions manual. |
