Trinocular Stereozoom Microscope :
We feel proud to introduce ourselves as the leading manufacturer, exporter and supplier of Trinocular Stereozoom Microscope. Our offered microscope is manufactured for low magnification observation of a sample. The microscope provided by us is used to carry out close work like dissection & microsurgery and also to study the sufaces of solid specimens. This microscope is designed using supreme class components with the help of cutting-edge technology under the able guidance of skilled professionals. Moreover, this microscope is available in various technical specifications as per requirements of clients and is highly admired for its durability and long working life. To deliver the flawless range at user' end, the offered Trinocular Stereozoom Microscope is examined on pre-defined parameters.
Features of Trinocular Stereozoom Microscope:
High power lenses
Excellent frame stability
Waterproof nose piece
Dust proof design
Specifications of Trinocular Stereozoom Microscope:
Trinocular tube with an inclination of 45 degree for greater ease of observation .
Magnification 7x to 45x
Microscope Zooming ratio 6.4:1
Rack-Pinion focussing stroke 50 mm.
Wide field eyepiece 10x (paired).
objective 0.7x to 4.5x.
Crisp,erect images with high resolution and excellent stereoscopic effect.
Standard working distance 100 mm,regardless of magnification.
Field of view 28.6-4.4 mm.
Interpupillary distance from 54 to 75 mm.
Dioptic adjustment with a range of + 5 diopters is possible with both oculars.
Trinocular body can be rotated a full 360 degree and locked in any position desried.
Once brought in focus, image remains clear and sharp throughout the whole zoom range.
Dual illumination system having circular fluorescent incident light and transmitted light through solid state built-in tranformer halogen bulb 6volts 20watts.
Packed in carboard box withopration manual, vinyl cover etc.
